Automatic pour point tester

summary

The automatic pour point tester meets the requirements of GB510 and GB / T 3535. The instrument adopts high-performance microprocessor and the latest semiconductor refrigeration technology, blue LCD, realizes Chinese character display and man-machine dialogue. The instrument has the function of self diagnosis, rapid, accurate, good repeatability, stability and reliability. It is a special instrument for electric power, petroleum and chemical industry to replace imported products.

technical parameter

Temperature measurement: platinum resistance
Accuracy: ± 1 ℃
L resolution: 0.1 ℃
L measurement range: 10 ℃ ~ - 70 ℃
L display: blue LCD (240 × 128)
L information storage: 100 data
L clock display: power failure hold
Oil test dosage: 20ml each time
L cooling water requirements: pressure 4.9 × 101 ~ 4.9 × 105Pa
L flow rate 1.5 L / min
L power supply voltage: ~ 220 V ± 22 V
L frequency: 50 Hz ± 2.5 Hz
L AC power: ≤ 250VA
L ambient temperature: 10 ~ 35 ℃
L ambient humidity: ≤ 85% RH
L weight: About 25kg
